12 Core SC/APC Full-Configured ODF Integrated Fiber Cross Connect Cabinet Splicing Tray
Description:
2 Core SC/APC Full-Configured ODF Integrated Splicing Tray— a telecom-grade, all-in-one fiber management solution designed for optical cross connect cabinets (OCC), ODF fiber distribution frames, and fiber optic splice closures. Engineered for FTTH (Fiber to the Home) deployments, telecom backbones, data centers, and multi-network convergence nodes, this integrated splicing tray combines fiber fusion splicing, storage, and distribution functions in a compact, full-configured design, featuring SC/APC connectors for low-loss signal transmission and seamless compatibility with standard fiber optic infrastructure.
As a professional manufacturer with standardized clean workshops, we craft our 12-core SC/APC ODF integrated trays to meet the rigorous demands of telecom operators, system integrators, and network builders worldwide. Fully compliant with IEC 61753, Telcordia GR-1081, and RoHS standards, this full-configured tray eliminates the need for additional components, enabling quick installation and reducing on-site labor costs—making it an ideal choice for large-scale fiber network deployments.
Key Features:
- 12-Core Full-Configured Design: Pre-installed 12 SC/APC adapters (UPC optional) and splicing sleeves, fully configured and ready to use right out of the box. Supports 12-core fiber termination, fusion splicing, and distribution in one integrated tray, maximizing fiber management efficiency and reducing on-site installation time.
- SC/APC Connector Compatibility: Equipped with standard SC/APC polished adapters, ensuring low insertion loss (≤0.2dB per port) and high return loss (≥60dB), minimizing signal degradation and ensuring stable, high-quality transmission for mission-critical fiber networks. Perfectly compatible with SC/APC fiber pigtails, patch cords, and ODF distribution frames.
- ODF & Fiber Cross Connect Cabinet Compatibility: Designed for seamless integration with standard ODF fiber distribution frames and optical cross connect cabinets (OCC), supporting 19-inch rack-mounted installation. The compact size (customizable) fits most telecom-grade fiber cabinets, facilitating centralized fiber management in data centers and telecom rooms.
- All-In-One Integrated Function: Combines fiber fusion splicing, fiber storage, and fiber distribution into a single tray—no need for separate splicing modules or storage components. Built-in fiber routing slots, splicing sleeves, and redundant fiber storage areas ensure neat fiber arrangement and minimize fiber bend damage (curvature radius ≥30mm).
- Telecom-Grade Durability: Crafted from high-strength engineering plastic (ABS/PC) with anti-aging, anti-corrosion, and flame-retardant properties. The rugged design withstands harsh operating environments (operating temperature: -40℃~+85℃), ensuring long service life and reliable performance in indoor/outdoor fiber cabinets.
- Easy Installation & Maintenance: Pull-out or flip-up design (optional) allows easy access to splicing and termination areas, simplifying on-site maintenance and network expansion. Clear labeling and standardized cable routing ensure quick identification and troubleshooting, reducing technician workload.
- Universal Fiber Compatibility: Fully compatible with single-mode fibers (G.652D, G.657A) and multi-mode fibers, supporting diverse network configurations. Ideal for FTTH access networks, telecom backbones, data center interconnections, and multi-network convergence projects.
- Strict Quality Control: Manufactured in our standardized clean workshops, each tray undergoes rigorous testing (insertion loss, return loss, structural stability) to meet international telecom standards. Backed by our 10000+ patents in fiber optic technology, ensuring consistent quality and performance.
| Item | Specification |
| Core Capacity | 12 Core |
| Connector Type | SC/APC (UPC optional) |
| Configuration | Full-Configured (Pre-installed adapters & splicing sleeves) |
| Material | High-Strength ABS/PC (Flame-Retardant, Anti-Corrosion) |
| Operating Temperature | -40℃ ~ +85℃ |
| Insertion Loss | ≤0.2dB per port |
| Return Loss | ≥60dB (SC/APC); ≥50dB (SC/UPC optional) |
| Compatibility | ODF Fiber Distribution Frames, Optical Cross Connect Cabinets (OCC), 19-Inch Racks |
| Fiber Type | Single-Mode (G.652D/G.657A), Multi-Mode |
| Compliance Standards | IEC 61753, Telcordia GR-1081, RoHS |
Applications
Widely applied in telecom-grade fiber network scenarios, including: ODF fiber distribution frames, optical cross connect cabinets (OCC), FTTH access networks, data center interconnections (DCI), telecom backbones, multi-network convergence nodes, residential/commercial fiber deployments, and campus fiber systems. Ideal for small-to-medium scale fiber management, where efficient splicing, termination, and distribution are required in a compact, full-configured solution.
